Tightening force of threaded connections, Nm
Note. The tightening forces are also indicated in the illustrations in the text of the chapter.
Nuts of fastening of a beam of a forward bumper to brackets | 12.7÷16.7 |
Front bumper bracket bolts | 20.6÷26.5 |
Bolt of fastening of an arm of the lock of a cowl | 20.6÷26.5 |
Bolts of fastening of an overlay of a forward bumper to a wing and locker | 5.1÷6.4 |
Screws of fastening of an overlay of a back bumper | 5.1÷6.4 |
Front spoiler mounting bolts | 5.1÷6.4 |
Nuts for fastening the hood to the hinges | 10.8÷14.6 |
Hood hinge bolts | 10.8÷14.6 |
Bonnet lock bolts | 20.6÷26.5 |
Bolts of fastening of the top basic beam of a radiator | 5.1÷6.4 |
Bolts of fastening of the bottom basic beam of a radiator | 43.4÷58.7 |
Wing bolts | 5.1÷6.4 |
Bolts of fastening of a loop of a door of a back | 20.6÷26.5 |
Nut of fastening of a loop of a door of a back | 51÷64.7 |
Screws of fastening of a drummer of the lock of a door of a back | 12.7÷15.7 |
Screws of fastening of a rack of a door of a back to a body | 5.0÷6.5 |
Bolts of fastening of assembly of the lock animals of a back | 8.4÷10.8 |
Nuts of fastening of the handle of a door of a back | 5.2÷6.2 |
Bolt of fastening of the limiter of a course of a lateral door | 12.5÷16.9 |
Side door hinge nuts | 20.8÷28.2 |
Side door hinge bolts | 17.5÷23.7 |
Screws of fastening of a drummer of a lateral door | 12.7÷20.6 |
Side door lock bolts | 5.1÷6.5 |
Bolt of fastening of the external handle of a lateral door | 5.1÷6.5 |
Bolts of fastening of an arm of the switch of management of the top hatch | 7÷9.5 |
Bolts of fastening of the e/motor of a drive of a cover of the top hatch | 2.5 |
Bolts and nuts for fastening the upper hatch assembly brackets | 5.1÷6.5 |
Nuts of fastening of assembly of the top hatch | 5.0÷6.5 |
Bolts of fastening of an external rear-view mirror | 5.4÷6.6 |
Bolts of fastening of windows and directing glasses of lateral doors | 5.2÷7.0 |
Bolts of fastening of a frame of a pillow of a forward seat | 8.1÷9.5 |
Bolts of fastening of assembly of guides of a forward seat | 25.5÷54.9 |
Bolts of fastening of an arm of the lever of adjustment of provision of a forward seat to assembly of directing | 8.1÷9.5 |
Nuts of fastening of internal strengthening of a forward seat | 4.9÷9.8 |
Nuts of fastening of the block of a lateral pillow of safety | 4.9÷9.8 |
Front seat back frame inner bolt | 53.9÷62.8 |
External bolt of fastening of a frame of a back of a forward seat | 43÷55 |
Bolts of fastening of locks of a back seat | 9.8÷12.7 |
Bolts of fastening of lateral brackets of a back seat | 20.6÷26.5 |
Bolts of fastening of guides and assembly of a back movable seat | 43÷55 |
